HDMI Audio Extractor ARC To Optical SPDIF Coaxial Analog 3.5mm L/R Stereo Audio

Onvian HDMI Audio Return Channel Adapter can transmit audio from from TV which must support ARC function to optical coaxial 3.5mm audio via HDMI/ARC interface , and output simultaneously, which perfectly solves problems of having no audio output interface that TV cannot be connected to the sound system.

Features: ¯¯¯¯¯¯¯¯

• Support SPDIF output
• Support Coaxial output
• Support RCA Stereo output
• Support 3.5mm stereo headphone output
• 3.5mm stereo headphone port equipped with high-performance audio. amplifier Support automatic signal mute function
• Support transmission of 192KHz audio sampling rate
• Optical fiber coaxial interface supports 5.1 channel transmission

Specifications: ¯¯¯¯¯¯¯¯¯¯¯¯¯

• HDMI ARC Audio Extractor Adapter Fiber Coaxial 3.5mm RCA Stereo Converter
• Warranty Period: 100 DAYS
• Material: Aluminium Alloy
• Power: DC5V/1A
• USB Type: Micro USB (Adapter not included)
• Max Operating Current: 65mA
• Size: 8 x 5.8 x 2.1cm
• Weight: Approx. 88g
• Colour: Black

Connection Diagram: ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯

1. Connect the HDMI port of adapter to the HDMI/ARC port of TV via an HDMI cable. Note: Please connect HDMI port with “ARC” mark
2. Use optic cable, coaxial cable or RCA cable and 3.5mm audio cable to connect to the amplifier system.
3. Connect the DC head of the power adapter to the DC input of the adapter and plug the adapter into the power outlet.
4. Turn the adapter switch to the ON position

Package Contents: ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯

1 * Adapter 1 * USB power Supply Cable (Adapter not included) 1 * User Manual
